4K Economical HDMI Switch 5 In 1 Out, IR Remote, HDCP 2.2SKU: 4KSW51
[email protected] with 5 Inputs and 1 Output:
Audio supports Dolby Atmos, DTS:X, Dolby TrueHD, DTS-HD Master, LPCM 2.1/ 5.1/ 7.1CH, provides great picture and fantastic audio.
IR remote control and “Switch” button on front panel.
No need an external Power supply:
Direct power-on from HDMI CABLE is safe and simple.
Small open vents on the sides which should ensure adequate ventilation to keep it cool. No driver needed.
Out of stock
5×1 4K HDMI Switch
4KSW51 is a 5-to-1 4K HDMI switcher. It is HDCP 2.2 compliant and supports resolutions up to [email protected] 4:2:0 8bit. It provides auto switch, remote control and button control on top panel, offering you flexible choice in switching. With its compact and exquisite design, the HDMI switcher can be used in any A/V applications, such as homes, offices, control centers, conference rooms and other locations which need A/V switching.
- Cost effective 5 to 1 4K HDMI switcher
- Supports up to [email protected] Hz 4:2:0 8bit
- HDCP 2.2 compliant
- HDMI input and output transmission distance up to 16ft/5m 16ft/5m at [email protected], and up to 10ft/3m 10ft/3m at [email protected] 4:2:0 8bit
- Can be powered by HDMI source devices
- Multi-channel PCM, Dolby and DTS HD audio supported up to 7.1
- Supports manual and auto switch
- Compact size for hidden installation
4K Ultra-HD Image
With five input ports and one output port, the compact HDMI switcher allows five Ultra HD sources to be switched to one Ultra HD display at resolutions up to [email protected] 4:2:0 8bit, delivering ultra-HD visual feast.
Excellent Audio Enjoyment
The HDMI switcher supports audio formats such as PCM 2.0/5.1/7.1, Dolby True HD and DTS HD Master Audio, so you can get fantastic audio experience.
The HDMI switcher is compatible with the latest HDMI source and display devices, such as Apple TV 4K, Roku 4, Amazon Fire TV 4K, Cisco cable box, Comcast, Xbox One X, PS4 Pro, Vizio TV, Sky Q. No more hesitation on choosing HDR or [email protected] for you could have both.
Flexible Control Options
The 5×1 HDMI switcher provides auto switch, IR remote control and button control on top panel, offering you flexible choice in switching. Now it is easier than ever to perform any A/V switching for your home or business.
|Video Signal type||HDMI with HDCP 2.2|
|Input/Output Resolution Supported|| SMPTE:
1280x720P1,2,3,4,5,6,7,8, 1920x1080I6,8, 1920x1080P1,2,3,4,5,6,7,8, 3840×21602,3,5,6,8,4096×21602,3,5,6,8
|Audio Format||PCM 2.0/5.1/7.1, Dolby True HD and DTS HD Master Audio|
|Control Method||IR remote control, Top panel switch button control|
|Power Consumption||0.25 W (Max)|
|Operating Temperature||32°F to 113°F (0°C to 45°C)
10% to 90%, non-condensing
|Storage Temperature||-4°F to 158°F (-20°C to 70°C)
10% to 90%, non-condensing
(W x D x H)
|3.94″ x 2.61″ x 0.71″
(100mm x 66.2mm x 18mm)
